Ricoh Pro C7500 - Loading Paper into the Wide Large Capacity Tray

M0EDIM0113
3. Press the elevator switch on the multi bypass tray (Tray A).
M0EDIM0114
1
1
1. Elevator switch
The lamp of the elevator switch blinks while the tray is moving upward and stays lit when it stops.
Press the elevator switch to move the tray downward to either add paper or remove jammed
paper.
Loading Paper into the Wide Large Capacity Tray
The wide LCT is identified as Tray 3, Tray 4, Tray 5, Tray 6, Tray 7, and Tray 8.
• Check the paper edges are aligned at the left side.
• Depending on the amount of paper curl, the upper limit exceeded notification may occur even if
the upper limit sign is not exceeded. When the upper limit exceeded notification occurs, remove the
loaded paper from the tray, and load it again.
2. Paper Specifications and Adding Paper
80
