Ricoh Pro C9500 - 0804: Applying Binding Glue

To Next Page

To Previous Page

On Head Edge

M0EDIM0224

On Tail Edge

M0EDIM0225

On Fore Edge

M0EDIM0226

Setting Items

Default

Value

Max.

Value

Min.

Value

Step Unit

01: Head Edge

02: Tail Edge

03: Fore Edge

0 10 -10 0.1 mm

0804: Applying Binding Glue

Adjust the amount of glue for Perfect Binding.

5. Adjustment Settings for Operators

218

Main Page
