Ricoh SR3250 - Sensors; Entrance Sensor (S9)

2.Replacement and Adjustment
24
Sensors
Entrance Sensor (S9)
1. Remove the internal finisher (Removing the Internal Finisher).
2. Remove the Open/Closed upper cover [A] ( ×2).
3. Remove the entrance sensor unit [A] ( ×1, ×1, ×1).
4. Remove the entrance sensor (S9) [A].
