Ricoh SR3250 - Tray Lift Motor (M15); Stack Height Lever Motor (M6)

2.Replacement and Adjustment
35
Tray Lift Motor (M15)
1. Remove the paper exit tray (Paper Exit Tray).
2. Remove the tray lift motor unit [A] ( ×2, ×1, ×1).
3. Remove the cam [A], bearing [B] ( ×1).
4. Remove the tray lift motor (M15) [A] ( ×2).
Stack Height Lever Motor (M6)
1. Remove the paper exit cover (Paper Exit Cover).
