Ricoh SR3250 - Motors; Entrance Motor (M10)

2.Replacement and Adjustment
34
Motors
Entrance Motor (M10)
1. Remove the internal finisher (Removing the Internal Finisher).
2. Remove the finisher right rear bracket [A] ( ×2)
3. Remove the rear cover [A] ( ×2).
4. Remove the entrance motor (M10) [A] ( ×2, ×1, Timing belt×1).
