Ricoh SR3250 - Stapler Tray Jam Sensor (S14); Paper Sensor (S19)

2.Replacement and Adjustment
32
Stapler Tray Jam Sensor (S14)
1. Remove the paper exit cover (Paper Exit Cover).
2. Remove the paper exit roller unit [A] ( ×1).
3. Remove the stapler tray jam sensor unit [A] ( ×1, ×1, ×1).
4. Remove the stapler tray jam sensor (S14) [A] ( ×1).
Paper Sensor (S19)
1. Remove the jogger fence motor (rear) (Jogger Fence Motor (Front) (M4), Jogger Fence Motor
(Rear) (M5))
