Ricoh SR3250 - Transport Sensor (S13)

2.Replacement and Adjustment
26
2. Remove the paper surface sensor (S17) [A] ( ×1).
Transport Sensor (S13)
1. Remove the finisher upper cover (Finisher Upper Cover).
2. Remove the transport sensor unit [A] ( ×1, ×1, ×1).
3. Remove the transport sensor (S13) [A].
