Ricoh SR3250 - Jogger Fence HP Sensor (Rear) (S16)

2.Replacement and Adjustment
31
3. Remove the jogger fence HP sensor (front) (S15) [A].
Jogger Fence HP Sensor (Rear) (S16)
1. Remove the paper exit cover (Paper Exit Cover).
2. Remove the jogger fence HP sensor (rear) unit [A] ( ×1, ×1).
3. Remove the jogger fence HP sensor (rear) (S16) [A].
