Operating Progeny Analyzers 31
1006232_RevD
Figure 14. Main Screen with Scan Options
2. From the Scan options, select (Analyze) to display the Analyze confirmation screen with the
laser warning (Figure 15).
Figure 15. Laser Warning
3. Select OK/ARM LASER to display the Analyze scan screen with the sample alignment diagram
(Figure 16).
Scan options
OK/ARM LASER
Extended screen
control
Laser warning
