User’s Guide for DS1000 Series
Key Points
Cursor Y: Cursors Y appear as horizontal lines on the display and measure the
vertical parameters. Usually it is used to measure the Volts. When the source is
set as function, the units are assigned to the function.
Cursor X: Cursors X appear as vertical lines on the display and measure the
horizontal parameters. Usually is indicates the time of trigger excursion. When
the source is set as FFT, X means frequency
