RIGOL
© Copyright RIGOL Technologies, Inc. 2007. 2-103
User’s Guide for DS1000 Series
NOTE: Horizontally moving cursor is not possible when other(not tracking cursor)
menu is activated.
(4) To get measurement value:
Position of Cursor 1 (Time cursor centered on the midpoint of screen; Voltage
cursor centered on channel ground level).
Position of Cursor 2 (Time cursor centered on the midpoint of screen; Voltage
cursor centered on channel ground level).
Horizontal space between cursor 1 and 2 (
△X): Time between cursors, units in
Second.
(1/
△X), units in Hz, kHz, MHz, GHz.
Vertical space between cursor 1 and 2 (
△Y): Voltage between cursors, units
in V.
