User’s Guide for DS1000 Series
and position of the Delayed Scan. The symbol at bottom of the screen means the
main time base and the symbol on the center bottom means the Delayed Scan time.
z Use the horizontal
knob to change the position of the expanded
portion.
z Turn the horizontal
knob to adjust the Delayed Scan resolution.
z To change the main time base, you must turn off the Delayed Scan mode.
z Since both the main and Delayed Scan are displayed; there are half as many
vertical divisions so the vertical scaling is doubled. Notice the changes in the
status bar.
Delayed Scan Shortcut Key:
Delayed Scan function can be activated not only by menu but also by pressing
horizontal
knob.
