DS6000 User’s Guide
16-2
Probe Attenuation
Coefficient
0.001X, 0.01X, 0.1X, 1X, 10X, 100X, 1000X
Maximum Input
Voltage (1MΩ)
Maximum Input Voltage of the Analog Channel
CAT I 300 Vrms, CAT II 100 Vrms,
Transient Overvoltage 1000V pk
with RP2200 10:1 probe: CAT II 300 Vrms
with RP3300 10:1 probe: CAT II 300 Vrms
with RP3500 10:1 probe: CAT II 300 Vrms
with RP5600 10:1 probe: CAT II 300 Vrms
Horizontal
Timebase Scale
DS606X: 1 ns/div to 50 s/div
DS610X: 500 ps/div to 50 s/div
Timebase Accuracy
≤ ± (15 + 2 × instrument age in years) ppm
Delay Range
Pre-trigger (negative delay): ≥1 screen width
Post-trigger (positive delay): 1 s to 1000 s
Timebase Mode
Y-T, X-Y, Roll, Time Delayed
Number of XYs
2 simultaneously
Waveform Capture
Rate
1
150,000 wfms (vector display); 180,000 wfms (dots display)
Vertical
Bandwidth (-3dB)
DS606X: DC to 600 MHz
DS610X: DC to 1 GHz
Single-shot
Bandwidth
DS606X: DC to 600 MHz
DS610X: DC to 1 GHz (each channel)
Vertical Resolution
8bits, two channels sample at the same time
Vertical Scale
2 mV/div to 5 V/div (1 MΩ)
2 mV/div to 1 V/div (50 Ω)
Offset Range
2 mV/div to 120 mV/div: ± 1.2V (50 Ω)
125 mV/div to 1 V/div: ± 12V (50 Ω)
2 mV/div to 225 mV/div: ± 2V (1MΩ)
