DS6000 User’s Guide
16-3
230 mV/div to 5 V/div: ± 40V (1MΩ)
Bandwidth Limit
2
20 MHz or 250 MHz
Low Frequency
Response
(AC Coupling -3dB)
≤5 Hz (on BNC)
Calculated Rise
Time
2
DS606X: 600 ps
DS610X: 400 ps
DC Gain Accuracy
± 2% full scale
DC Offset Accuracy
200 mV/div to 5 V/div: 0.1 div ± 2 mV± 0.5% offset value
2 mV/div to 195 mV/div: 0.1 div ± 2 mV± 1.5% offset value
ESD Tolerance
±2 kV
Channel to Channel
Isolation
DC to maximum band width: >40 dB
Trigger
Trigger Level Range
Internal
± 6 div from center screen
EXT
± 0.8 V
Trigger Mode
Auto, Normal, Single
Holdoff Range
100 ns to 10 s
High Frequency
Rejection
2
50 kHz
Low Frequency
Rejection
2
5 kHz
Edge Trigger
Edge Type
Rising, Falling, Rising&Falling
Pulse Trigger
Pulse Condition
Positive Pulse Width (greater than, lower than, within
specific interval)
Negative Pulse Width (greater than, lower than, within
specific interval)
Pulse Width Range
4 ns to 4 s
Slope Trigger
Slope Condition
Positive Slope (greater than, lower than, within specific
interval)
