Negative Slope (greater than, lower than, within specific
interval)
Time Setting
10 ns to 1 s
Video Trigger
Signal Standard
Line Frequency
Range
Support standard NTSC, PAL and SECAM broadcasting
standards, the range of the number of lines is from 1 to 525
(NTSC) and 1 to 625 (PAL/SECAM)
Pattern Trigger
Pattern Setting
H, L, X, Rising Edge, Falling Edge
RS232/UART Trigger
Trigger Condition
Start, Error, Check Error, Data
Baud Rate
2400bps, 4800bps, 9600bps, 19200bps, 38400bps,
57600bps, 115200bps, User
Data Bits
5 bit, 6 bit, 7 bit, 8 bit
I2C Trigger
Trigger Condition
Start, Restart, Stop, Missing ACK, Address, Data, A&D
Address Bits
7 bit, 10 bit
Address Range
0 to 119, 0 to 1023
Byte Length
1 to 5
Data Qualifier
Equal to, Greater than, Less than
SPI Trigger
Trigger Condition
CS, Timeout
Timeout Value
100 ns to 1 s
Data Bits
4 bit to 32 bit
Data Line Setting
H, L, X
Clock Edge
Rising Edge, Falling Edge
Signal Type
Rx, Tx, CAN_H, CAN_L, Differential
CAN Trigger
Trigger Condition
SOF, EOF, Frame Type
Baud Rate
10kbps, 20kbps, 33.3kbps, 50kbps, 62.5kbps, 83.3kbps,
100kbps, 125kbps, 250kbps, 500kbps, 800kbps, 1Mbps,
User
Sample Point
5% to 95%
Frame Type
Data, Remote, Error, OverLoad
USB Trigger
Signal Speed
Low Speed, Full Speed
