DS6000 User’s Guide
16-6
FFT Vertical
Scale
Linear RMS, dBV RMS
Logic
Operation
AND, OR, NOT, XOR
Math Function
Intg, Diff, Log, Exp, Sqrt, Sine, Cosine, Tangent
Number of
Buses for
Decoding
2
Decoding Type
Parallel (standard), RS232/UART (option), I2C (option) , SPI
(DS6XX4 option), CAN (option)
Display
Display Type
10.1 inches (257 mm) TFT LCD display
Display Resolution
800 Horizontal × RGB× 480 Vertical Pixel
Display Color
160,000 Color
Persistence Time
Minimum, 50 ms, 100 ms, 200 ms, 500ms, 1 s, 2 s, 5 s, 10 s,
20 s, Infinite
Display Type
Dots, Vectors
Real-time Clock
Time and Date (user adjustable)
I/O
Standard Ports
USB device, two USB host ports, LAN, VGA Output, 10 MHz
Input/Output, Aux output ( TrigOut, Quick Edge, PassFail,
Calibration, GND)
Printer Compatibility
PictBridge
General Specifications
Probe Compensation Output
Output Voltage
2
About 3 V, peak-peak
Frequency
2
1kHz
