RIGOL Chapter 6 Operations and Measurements
6-26 MSO5000 User Guide
⚫ Press More → Label to set the label for math operation results. For details,
refer to descriptions in "Math Operation Label".
⚫ Press More → Color Grade to enable or disable the color grade display of the
operation results. When enabled, different colors are displayed on the screen to
indicate the times of data acquisition or acquisition probability.
⚫ Press More → Reset ColorGrade to clear the color grade display and display
the color grade again.
Math Operation Label
Press Label to enter the label setting menu.
⚫ Press Display Label continuously to enable or disable the label display of the
waveform. If it is enabled, the label will be displayed at the left side of the
waveform.
⚫ Press Library to select the preset waveform label, including ADD, SUB, MUL,
DIV, FFT, AND, OR, XOR, NOT, Intg, Diff, Sqrt, Lg, Ln, Exp, Abs, LPas, HPas, BPas,
Bstop, and AX+B.
⚫ Press Label, and the label editing interface is automatically displayed. You can
input the label manually. For details, refer to descriptions in "Channel Label".

Rigol MSO5074 Specifications

General

Bandwidth	70 MHz
Channels	4
Timebase Accuracy	± 2 ppm
Operating Temperature	0 °C to +40 °C
Display	800x480
Waveform Capture Rate	500, 000 wfms/s
Vertical Resolution	8 bits
Interfaces	USB Host, USB Device, LAN, HDMI
Input Impedance	1 MΩ
Trigger Types	Edge, Slope, Pulse, Video, Pattern, Duration, Timeout, Window, Runt
Sample Rate	8 GSa/s
