Rigol MSO5074 User Manual

Chapter 10 Digital Channel RIGOL
MSO5000 User Guide 10-1
Chapter 10 Digital Channel
MSO5000 series oscilloscope has an standard configuration of the logic analyzer (LA)
function, and it has 16 digital channels. The default channel label is D15-D0. The
oscilloscope compares the voltages acquired in each sample with the preset logic
threshold. If the voltage of the sample point is greater than the threshold, it will be
stored as logic 1; otherwise, it will be stored as logic 0. The oscilloscope displays
logic levels ("1" and "0") in the form of a graph for you to easily detect and analyze
the errors in circuit design (hardware design and software design).
Before using the digital channels, connect the oscilloscope and the device under test
using PLA2216 active logic probe option. To apply to different application scenarios,
PLA2216 provides two connection methods to connect the signal under test. For
details, refer to PLA2216 Active Logic Probe User’s Guide .
Note: The digital channel input terminal does not support hot plug. Please do not
insert or pull out the logic probe when the instrument is powered on.
Contents in this chapter:
◼ To Select the Digital Channel
◼ To Enable/Disable the Digital Channel
◼ To Set the Threshold and Calibrate Probe
◼ Auto Arrangement Setting
◼ To Set the Waveform Display Size
◼ To Set the Label
◼ Group Setting
◼ Waveform Color of the Digital Channel

Rigol MSO5074 Specifications

General

Bandwidth	70 MHz
Channels	4
Timebase Accuracy	± 2 ppm
Operating Temperature	0 °C to +40 °C
Display	800x480
Waveform Capture Rate	500, 000 wfms/s
Vertical Resolution	8 bits
Interfaces	USB Host, USB Device, LAN, HDMI
Input Impedance	1 MΩ
Trigger Types	Edge, Slope, Pulse, Video, Pattern, Duration, Timeout, Window, Runt
Sample Rate	8 GSa/s
