Rigol MSO5074 User Manual

Chapter 12 Reference Waveform RIGOL
MSO5000 User Guide 12-5
To Export to Internal or External Memory
You can also save the current reference waveform to the internal memory or external
USB storage device. The file format of the reference waveform is ".ref", ".bin", or
".csv".
Press More → Export to enter the reference waveform file saving interface. Please
refer to descriptions in "Store and Load" to save the reference waveform to the
internal or external memory. Only when the reference waveform is saved, can this
export function is valid.
Note: MSO5000 series oscilloscope only supports the flash memory USB storage
device of FAT32 format.
To Import from Internal or External Memory
You can also import the stored reference waveform file from the internal memory or
external USB storage device to the instrument and display the file on the screen.
Press More → Import to enter the reference waveform file loading interface. Please
refer to descriptions in "Store and Load" to import the reference waveform to the
instrument and display it on the screen.
Note: MSO5000 series oscilloscope only supports the flash memory USB storage
device of FAT32 format.

Rigol MSO5074 Specifications

General

Bandwidth	70 MHz
Channels	4
Timebase Accuracy	± 2 ppm
Operating Temperature	0 °C to +40 °C
Display	800x480
Waveform Capture Rate	500, 000 wfms/s
Vertical Resolution	8 bits
Interfaces	USB Host, USB Device, LAN, HDMI
Input Impedance	1 MΩ
Trigger Types	Edge, Slope, Pulse, Video, Pattern, Duration, Timeout, Window, Runt
Sample Rate	8 GSa/s
