Rigol MSO5074 User Manual

RIGOL Chapter 16 Display Control
16-4 MSO5000 User Guide
range available is from 1% to 100%.
Scale
Press Show Scale continuously to enable or disable the scale display on the screen.
By default, it is set to "OFF".
Note: When the digital channel is enabled, the scale in the vertical direction is
hidden automatically.
Color Grade
Press More → Color Grade to enable or disable the color grade display of the
analog channel waveforms on the screen. By default, it is set to "OFF". When
enabled, different colors are displayed on the screen to indicate the times of data
acquisition or acquisition probability.
Waveform Freeze
Press More → Waveform Freeze to enable or disable waveform freeze function. If
enabled, when you press the RUN/STOP key, the current waveform display
(including the history waveforms) will be frozen. If disabled, when you press the
RUN/STOP key, only the last acquired waveform will be displayed.

Rigol MSO5074 Specifications

General

Bandwidth	70 MHz
Channels	4
Timebase Accuracy	± 2 ppm
Operating Temperature	0 °C to +40 °C
Display	800x480
Waveform Capture Rate	500, 000 wfms/s
Vertical Resolution	8 bits
Interfaces	USB Host, USB Device, LAN, HDMI
Input Impedance	1 MΩ
Trigger Types	Edge, Slope, Pulse, Video, Pattern, Duration, Timeout, Window, Runt
Sample Rate	8 GSa/s
