Chapter 6 Operations and Measurements RIGOL

MSO5000 User Guide 6-29

Note: The waveform auto setting function requires that the frequency of the signal

should be greater than or equal to 35 Hz, the amplitude greater than or equal to 5

mV. If not meeting the conditions, the waveform auto setting function may be invalid.
