Chapter 2 Functions of the Front Panel of GPSA RIGOL
RSA3000E User Guide 2-43
Time-domain Power (T-Power)
Measurement Interface:
Figure 2-5 T-Power Measurement Interface
Measurement Result: T-power, i.g. the power of the signal from the start line to
stop line.
Measurement Parameters: average count, average mode, average auto, power
type, start line, and stop line.
1. Avg Number
Specifies the number of times for averaging the measurement results. You can
use the numeric keys, the knob, or arrow keys to modify this parameter; you can
also use the touch screen to modify the parameter.
Table 2-31 Average Count of T-Power Measurement
1
Left/Right Arrow Key Step
Measurement Result Measurement Parameters
To Next Page
