RIGOL Chapter 2 Functions of the Front Panel of GPSA
2-60 RSA3000E User Guide
range is from (noise bandwidth/20) to (noise bandwidth x 20).
 You can use the numeric keys, the knob, or arrow keys to modify this
parameter; you can also use the touch screen to modify the parameter.
Table 2-49 Carrier Bandwidth for C/N Ratio Measurement
Parameter
Remarks
Default
2 MHz
Range
3 Hz to 1 GHz
Unit
GHz, MHz, kHz, Hz
Knob Step
carrier noise/100, Min = 1 Hz
Left/Right Arrow Key Step
Up/Down Arrow Key Step
at 1-1.5-2-3-5-7.5 step
For details about the Auto Couple and Meas Preset menus, refer to their
descriptions on Page
2-45.
