Rigol RSA3000E Series User Manual

RIGOL Chapter 3 Functions of the Front Panel of RTSA
3-36 RSA3000E User Guide
Sweep
Acq Time
Auto, 32 ms
Auto, 31.9460 ms
Sweep Mode
Continuous
Trigger
Trigger Source
Free Run
Trigger Hold-off
Off, 100 ms
Auto Trig
Off, 100 ms
Slope
Positive
Trig Delay
Off, 1 us
Acq/Trigger
1
Power
0 dBm
Mask Type
Upper
Trigger Mask
Upper
Trigger Criteria
Enter
Active Mask
Upper
Frequency
1.4989950 GHz
Amplitude
0 dBm
Build From Trace
Trace 1
X Offset
0 Hz
Y Offset
0 dB
X Axis Type
Fixed
Y Axis Type
Fixed
Trace
Selected Trace
Trace 1
--
Trace Type
Clear Write
--
Trace Det
Pos Peak
Pos Peak
Detector Auto
Off
On
Trace Update
On
On
Trace Display
On
On
Mode Setup
Global CF Mode
On, 1.5 GHz
Meas
Measurement
Function
Density
Measure Setup
Normal
Avg Number
100
Test Limits
Off
Select Limit
Limit 1
Limit State
Off
Test Trace
Trace1
Limit Type
Upper
X to CF
Fixed
Y to Ref
Fixed
