Rigol RSA3000E Series User Manual

Chapter 3 Functions of the Front Panel of RTSA RIGOL
RSA3000E User Guide 3-37
Margin
Off, 0 dB
Frequency
0 Hz
Amplitude
0 dBm
Build From
Trace1
X Offset
0 Hz
Y Offset
0 dB
Density
Avg Number
10
Persistence
300 ms
Pers Inf
Off
Color Palettes
Warm
Highest Density Hue
100
Lowest Density Hue
0
Curve Nonlinearity
75
Hue Truncate
Off
Spectrogram
Avg Number
100
Display Trace
1
Trace Selection
TNum
Couple Marker Trace
On
Ref Hue
0
Ref Hue Pos
100
Bottom Hue Pos
0
SSC
Max Hold
Off
Mark Line1
Off, 1.495 GHz
Mark Line2
Off, 1.505 GHz
Pass/Fail
Off
Signal
1
Ampt Up
-10 dBm
Ampt Down
-100 dBm
Marker
Selected Marker
Marker 1
Marker 1
Marker Mode
Position
Position
Reference Marker
Marker 2
Marker 2
Marker Trace
Trace 1
--
Marker Trace Auto
On
--
Marker Freq/Time
1.5 GHz
15.9730 ms
Marker Readout
Frequency
--
Readout Auto
On
--
Line State
Off
Off
Couple Markers
Off
Off
Marker Table
Off
Off
Peak
