Chapter 4 Functions of the Front Panel of EMI RIGOL
RSA3000E User Guide 4-17
CISPR Average, RMS Average, Average(Vol), and Neg Peak.
1. Pos Peak
For each trace point, Positive Peak detector displays the maximum value of data
sampled within the corresponding time interval.
2. Quasi-Peak
The quasi-peak detector is implemented according to CISPR standard.
3. CISPR Average
The average detector is implemented according to CISPR standard.
4. RMS Average
The RMS average detector is implemented according to CISPR standard.
5. Average
For each data point, average (see equation (2-9)) all the sampled data within
the corresponding time interval and display the result.
∑
=
×
=
N
iAV
v
N
V
1i
1
(4-7)
Wherein,
AV
V
is the average of voltage in V;
N
is the number of sampled
values for each point displayed;
i
v
is the envelope of the sampled value in V.
6. Neg Peak
For each trace point, Negative Peak detector displays the minimum value of data
sampled within the corresponding time interval.
Detector Auto
Enables or disables the Detector Auto function. By default, Detector Auto is enabled.
If you set the detector type manually, the Detector Auto function is disabled
automatically.
Trace Update
Enables or disables trace update.
