rletech.com WiNG-MGR v2 User Guide 61
3 Web Interface
Radio C (Digi) If your system uses a WiNG-RXT range extender, make sure radio C
is on and select the appropriate type of connection:
Enabled - Broadcast: Choose this option if you have one WiNG-MGR
and one or more WiNG-RXTs.
The WiNG-MGR will receive incoming transmissions from all
unbound WiNG-RXTs and all unbound WiNG-RXTs will be
configured for the channel pair specified.
Enabled - Binding: Choose this option if you have multiple WiNG-
MGRs and WiNG-RXTs in a single space. You can select specific
range extenders by serial number to bind them to the WiNG-MGR.
This setting reduces radio conflict and allows multiple systems on
different channel pairs to exist in the same space. The WiNG-MGR
will only receive packets from the WiNG-RXTs it is bound to and the
WiNG-RXT’s channel pair can only be configured by the WiNG-MGR
that it is bound to.
Default: Enabled - Broadcast
Manager Frequency
Channel Pair
If you wish to change the channel pair on which your system is
communicating, refer to Appendix C, “Alternate Channel Pair
Communications” on page 83.
Default: Channel pair 1
Range Extender
Frequency Channel
Pair
If you wish to change the channel pair on which your system is
communicating, refer to Appendix C, “Alternate Channel Pair
Communications” on page 83.
Default: Channel pair 1
Radio Status - These fields provide detailed information about the status and operation of
the WiNG-MGR’s radios. The Spectrum field tells you if this unit operates on the 900MHz or
868MHz frequency. If you need to make a call to RLE tech support, they may request
information found in these fields.
Attribute Description
Table 3.21
Radio Configuration Options
