RLE Technologies WiNG-MGR v2 - E Technical Specifications

rletech.com WiNG-MGR v2 User Guide 91
A P P E N D I X
E
CHAPTER 3TECHNICAL SPECIFICATIONS
WiNG-MGR v2
Power
Voltage Rating 24VAC, 50/60Hz; 24VDC, 600mA
Current Rating 600mA max
Wired Relay Outputs Two (2) Dry Contact, Form C, 1A @ 24VDC resistive,
0.5A @ 120VAC
Communications Ports
Ethernet 10/100 BASE-T, RJ-45 connector; 500VAC RMS isolation
EIA-485 9600, 19200, or 38400 baud; no parity; 8 data bits; 1 stop
bit
USB Serial port emulation for diagnostics; 115200 baud; no
parity; 8 data bits; 1 stop bit
Protocols
TCP/IP, HTML, SNMP IPv4. IPv6; HTTP/HTTPS (TLS1.2); V1, V2C, V3
Modbus (EIA-485) Modbus Server
Modus TCP/IP Modbus Server; TCP/IP transmission protocol
BACnet/IP ASHRAE STD 135-2004 Annex J
BACnet MS/TP EIA-485
Wireless Communications
Frequency Range 868-870MHz / 902-928MHz
Max Number of Wireless Sensors
Per Manager
RLE recommends not exceeding 250 sensors per WiNG-
MGR; 400 sensors per WiNG-MGR may be accomplished
with range extenders, but signal conflict will increase.
Antenna Three (3) 868-928MHz with RP/SMA connectors
Login Security Web browser access (Ethernet); Four (4) users and
passwords can be configured
Table E.1 WiNG-MGR Technical Specifications
