72 WiNG-MGR v2 User Guide 800.518.1519

4.3. RTU Framing

The example below shows a typical Query/Response from a WiNG-MGR.

Unit ID 2 responds to Function Code 4 with six bytes of hexadecimal data and ends with

CRC16 checksum.

40001 = 0000 (hex)

40002 = 0000 (hex)

40003 = 0001 (hex)

Unit ID

Function

Code

Count

Bytes

of Data

Data

Msb Lsb

Data

Msb Lsb

Data

Msb Lsb

CRC 16

“Lsb”

CRC 16

“Msb”

02 04 06 00 ----- 00 00 ----- 00 00 ----- 01 B5 A3

Table 4.5

Response Sample
