64 WiNG-MGR v2 User Guide 800.518.1519

3 Web Interface

Humidity Under Enter a low humidity warning threshold - if the humidity drops below

this value, a low humidity warning is generated.

Check the box to activate the option and enter a humidity value.

Warning Delays The number of seconds that pass between the time a temperature

or humidity reading goes into a warning state and the time that

warning is announced.

Check the box to activate the option and enter a time interval.

Option Description

Table 3.22

Alarms Configuration Options

Main Page
