PPPoE Settings
Username
Enter the username provided by your Internet Service Provider.
Null
Password
Enter the password provided by your Internet Service Provider.
Null
Authentication Type
Select from “Auto”, “PAP” or “CHAP” as the local ISP required.
Auto
PPP Expert Options
Enter the PPP Expert options used for PPPoE dialup. You can enter some
other PPP dial strings in this field. Each string can be separated by a
semicolon.
Null
Ping Detection Settings
Enable
Click the toggle button to enable/disable the ping detection mechanism, a
keepalive policy of the router.
ON
Primary Server
Router will ping this primary address/domain name to check that if the
current connectivity is active.
8.8.8.8
Secondary Server
Router will ping this secondary address/domain name to check that if the
current connectivity is active.
114.114.11
4.114
Interval
Set the ping interval.
300
Retry Interval
Set the ping retry interval. When ping failed, the router will ping again
every retry interval.
5
Timeout
Set the ping timeout.
3
Max Ping Tries
Set the max ping tries. Switch to another link or take emergency action if
the max continuous ping tries reached.
3
Advanced Settings
NAT Enable
Click the toggle button to enable/disable the Network Address Translation
option.
ON
MTU
Enter the Maximum Transmission Unit.
1500
Upload Bandwidth
Enter the upload bandwidth used for QoS, measured in kbps.
10000
Download Bandwidth
Enter the download bandwidth used for QoS, measured in kbps.
10000
Overrided Primary
DNS
Override primary DNS will override the automatically obtained DNS.
Null
Overrided Secondary
DNS
Override secondary DNS will override the automatically obtained DNS.
Null
Debug Enable
Click the toggle button to enable/disable this option. Enable for debugging
information output.
ON
Verbose Debug Enable
Click the toggle button to enable/disable this option. Enable for verbose
debugging information output.
OFF
