Rockwell Automation 1794-AENTR, 1794-AENTRXT User Manual

Rockwell Automation Publication 1794-UM066C-EN-E - April 2023 11
Chapter 2
Install Your FLEX I/O Adapter
Overview This chapter describes how to physically install the 1794-AENTR or 1794-AENTRXT adapter on the
DIN rail and connect it to the EtherNet/IP network.
Module Components Use Figure 2 to identify the external features of the FLEX I/O EtherNet/IP adapter.
Figure 2 - Dual-port EtherNet/IP Adapter – 1794-AENTR, 1794-AENTRXT
Component Identification
1 Dual-port EtherNet/IP adapter 6 Module locking tab
2 Flexbus connector 7 Network cable RJ45 connectors (underside)
3 24V common connections 8 MAC ID label
4 24V DC connections 9 Status indicators
5 IP address switches
1
9
8
7
5
6
3
2
4
