Chapter 2 Non-regenerative Common DC-bus Configurations
Typical System Configuration
In this example, standalone AC drives, Kinetix 6000 drives, and Kinetix 7000 drives receive DC-bus power from three 2198-P208 DC-bus
power supplies.
Figure 12 - DC-bus Supply with Standalone AC Drives, Kinetix 6x00 Drives, and Kinetix 7000 Drives
(1) Line reactors are required when three 2198-P208 DC-bus supplies are configured. For line reactor considerations and selection when one or two 2198-P208 DC-bus supplies are configured,
see the Kinetix 5700 Servo Drives User Manual, publication 2198-UM002
.
Table 3 - Special Bus Requirements
Drawing Designation Supported Drives Special Bus Requirements
AC drives
PowerFlex 750-Series: Frames 1…6
NoneKinetix 7000: 2099-BM06-S…2099-BM08-S
Kinetix 7000: 2099-BM09-S…2099-BM12-S
Kinetix 6000 and
Kinetix 6200/6500 drives
Kinetix 6000: All 460V configurations
(1)
(1) No internal precharge. Drives must be placed in common-bus follower configuration.
None
Kinetix 6200/6500: All 460V configurations
(1)
2198-P208
2198-CAPMOD-2240
2198-CAPMOD-DCBUS-IO
2198-P208
2198-P208
Three-phase
Source
DC+
DC-
M
DC+
DC-
M
AC Drive AC Drive
M
M
M
Kinetix 6000 or
Kinetix 6200/6500 Drives
DC+ DC-
Contactor
Three-phase
Capacitor
Module
DC-Bus
Power Supply
Extension
Module
DC Bus
DC-Bus
Power Supply
DC-Bus
Power Supply
Reactor
Line
Reactor
Line
Reactor
Line
AC Line Filter
Three-phase
Circuit
Protection
Circuit
Protection
Circuit
Protection
M
Circuit
Protection
Integrated
Axis Module
Axis
Modules
(1)
(1)
(1)
