Rockwell Automation Publication MOTION-AT007A-EN-P - May 2020 45
Chapter 5
Regenerative Bus Supply Configurations With Active Shunt
This system also uses a PWM-controlled IGBT converter for regeneration of power to the AC line. However, in this configuration some
regenerative DC-bus energy flows to the incoming AC line, but DC-bus energy that is not regenerated is dissipated to an external shunt
resistor (braking) unit. This configuration provides low AC-line harmonics and can be used to meet IEEE-519. Contact our Encompass™
Partners for these shunt resistor (braking) products.
Supported Products
At the time of publication, the following products are supported.
When applicable, the drive's internal IGBT can be used with a passive shunt.
Table 32 - Kinetix 5700 Regenerative Bus Supply Modules
Regenerative Bus Supply
Cat. No.
Supported Drives
•2198-RP088
•2198-RP200
•2198-RP263
•2198-RP312
PowerFlex® 750-Series: Frames 1…6
(1)
(1) PowerFlex 750-Series (Frames 5 and 6) DC input version drives with precharge must be selected.
Kinetix® 7000: 2099-BM06-S…2099-BM12-S
Kinetix 6000 and Kinetix 6200/6500: All 460V configurations
(2)
(2) Kinetix 6000 configurations require firmware revision 1.92 or later.
Drive Family Internal Brake IGBT
PowerFlex 750-Series Standard on Frames 1…5, optional on Frame 6.
Kinetix 7000 No internal brake IGBT.
Kinetix 6000 (400V-class) and Kinetix 6200/6500 Internal bus regulation cannot be used.
IMPORTANT The internal IGBT in Kinetix 6000 (460V) drives and Kinetix 6200/6500 drives are disabled in Common Bus Follower mode.
