Rockwell Automation Publication MOTION-AT007A-EN-P - May 2020 63
Kinetix and PowerFlex Drive Specifications Appendix A
Kinetix 6200 and Kinetix 6500 Drive Specifications
When using a non-Bulletin 2094 common-bus leader drive, DC-bus fuses are required in both lines of the DC-bus. For example, between the
common-bus leader drive and follower IAM module. Base these fuse ratings on the DC output current of the common-bus leader drive. When
using more than one follower IAM module, install fuses in both lines of the DC-bus. For example, between the non-Bulletin 2094 common-bus
leader and the terminal block, and between the DC-bus terminal block and each follower IAM module.
The 2094-BCxx-Mxx-M and 2094-BMxx-M drive modules use internal solid-state motor short-circuit protection and, when protected by
suitable branch circuit protection, are rated for use on a circuit capable of delivering up to 200,000 A (fuses) and 65,000 A (circuit breakers).
Table 54 - DC-bus Circuit-protection Specifications
IAM Power Module
Cat. No.
DC-bus Power
Bussmann Fuse
Mersen Fuse
(1)
(1) Mersen fuses were formerly known as Ferraz Shawmut.
2094-BC01-MP5-M
FWJ-20A14F DCT20-2
2094-BC01-M01-M
2094-BC02-M02-M FWJ-40A A70QS40-4
2094-BC04-M03-M FWJ-70A A70QS70-4
2094-BC07-M05-M FWJ-125A A70QS125-4
Table 55 - IAM Module (converter, 400V-class) Power Specifications
Attribute 2094-BC01-MP5-M 2094-BC01-M01-M 2094-BC02-M02-M 2094-BC04-M03-M 2094-BC07-M05-M
AC input voltage
324…528V rms
three-phase (360…480V nom)
DC input voltage (common bus follower) 458…747V DC
DC input current (common-bus follower) 9.0 A 22.6 A 41.5 A 67.7 A
Continuous power output to bus 6 kW 15 kW 27.6 kW 45 kW
Converter capacitance 110 F 220 F940 F1410 F
Table 56 - AM Module (inverter, 400V-class) Power Specifications
Attribute
2094-BMP5-M
(2094-BC01-MP5-M)
2094-BM01-M
(2094-BC01-M01-M)
2094-BM02-M
(2094-BC02-M02-M)
2094-BM03-M
(2094-BC04-M03-M)
2094-BM05-M
(2094-BC07-M05-M)
Capacitance 75 F150 F270 F840 F1175 F
