Rockwell Automation Publication MOTION-AT007A-EN-P - May 2020 25
Chapter 3
Non-regenerative Common DC-bus Configurations
With Passive or Active Shunt
This system also uses a diode-front-end power supply that converts the three-phase AC line voltage into a non-filtered DC-bus voltage.
However, in this configuration the drive uses the internal IGBT shunt resistor or an external passive or active shunt for power dissipation of
excess regenerative energy. Rockwell Automation does not offer external active shunt products. Contact our Encompass™ Partners for these
shunt resistor (braking chopper) products.
Supported Products
At the time of publication, the following Kinetix® 5700 non-regenerative DC-bus supplies and drives are supported.
Table 10 - Kinetix 5700 Non-regenerative Drive Modules
DC-bus Power Supply
Cat. No.
Supported Drives
• 2198-P031
• 2198-P070
• 2198-P141
• 2198-P208
PowerFlex® 750-Series: Frames 1…6
(1)
(1) PowerFlex 750-Series (Frames 5 and 6) DC input version drives with precharge must be selected.
Kinetix 7000: 2099-BM06-S…2099-BM12-S
Kinetix 6000 and Kinetix 6200/6500: All 460V configurations
(2)
(2) Kinetix 6000 configurations require firmware revision 1.92 or later.
