Rockwell Automation Publication MOTION-AT007A-EN-P - May 2020 37
Chapter 4
Regenerative Bus Supply Configurations
Regenerative bus supplies use a PWM-controlled IGBT converter for full regeneration of power to the AC line. The regenerative bus supply
returns energy back to the distribution system instead of dissipating energy with shunt resistor (braking) technology. This configuration
provides low AC-line harmonics and can be used to meet IEEE-519.
Supported Products
At the time of publication, the following products are supported.
Table 23 - Kinetix 5700 Regenerative Bus Supply Modules
Regenerative Bus Supply
Cat. No.
Supported Drives
•2198-RP088
•2198-RP200
•2198-RP263
•2198-RP312
PowerFlex® 750-Series: Frames 1…6
(1)
(1) PowerFlex 750-Series (Frames 5 and 6) DC input version drives with precharge must be selected.
Kinetix® 7000: 2099-BM06-S…2099-BM12-S
Kinetix 6000 and Kinetix 6200/6500: All 460V configurations
(2)
(2) Kinetix 6000 configurations require firmware revision 1.92 or later.
IMPORTANT The internal IGBT in Kinetix 6000 (460V) drives and Kinetix 6200/6500 drives are disabled in Common Bus Follower mode.
