Appendix A Kinetix and PowerFlex Drive Specifications
Kinetix 7000 Drive Specifications
The following fuse examples and short-circuit current ratings are recommended for use with the 2099-BMxx-S drives when the line interface
module (LIM) is not used.
Table 57 - Ferraz Shawmut Fuse Recommendations
Drive Cat. No.
Drive Current
Rating (ADC)
Recommended Fuse
Fuse Current
Rating
i²t (A²sec)
Peak Let-through Current
@ 100 kA rms
Pre-arc
Clearing @ 600V AC,
max
2099-BM06-S 42.9 HSJ80 80 1600 15000 7000 A
2099-BM07-S 55.7 HSJ90 90 2300 21000 7400 A
2099-BM08-S 69.7 HSJ100 100 2700 23000 7700 A
2099-BM09-S 105 HSJ175 175 8000 60000 12000 A
2099-BM10-S 137 HSJ200 200 14000 92000 13000 A
2099-BM11-S 204 HSJ400 400 63000 450000 21000 A
2099-BM12-S 281 HSJ400 400 63000 450000 21000 A
Table 58 - Bussmann Fuse Recommendations
Drive Cat. No.
Drive Current
Rating (ADC)
Recommended Fuse Fuse Current Rating
i²t (A²sec)
Peak Let-through Current
@ 100 kA rms
Pre-arc
Clearing @ 600V AC,
max
2099-BM06-S 42.9 FWJ-80A 80 1550 9700 6300 A
2099-BM07-S 55.7 FWJ-100A 100 2800 17500 8000 A
2099-BM08-S 69.7 FWJ-125A 125 4800 35000 10000 A
2099-BM09-S 105 FWJ-175A 175 7500 65000 12000 A
2099-BM10-S 137 FWJ-200A 200 11700 80000 13000 A
2099-BM11-S 204 FWJ-500A 500 39500 329000 21000 A
2099-BM12-S 281 FWJ-500A 500 39500 329000 21000 A
Table 59 - Kinetix 7000 Drive Power Specifications
Attribute 2099-BM06-S 2099-BM07-S 2099-BM08-S 2099-BM09-S 2099-BM10-S 2099-BM11-S 2099-BM12-S
AC input voltage 342…528V AC rms three-phase (380…480V nom)
DC input voltage 450…750V DC
DC input current 42.9 A 55.7 A 69.7 A 105 A 137 A 204 A 281 A
Continuous power output, nom 22 kW 30 kW 37 kW 56 kW 75 kW 112 kW 149 kW
Total capacitance
(1)
(1) If DC input is supplied to 2099-BM09-S, 2099-BM10-S, or 2099-BM11-S drives, the precharge capability must be provided at the system level. Disconnect switches must not be used between
the input of the drive and a common DC-bus without the use of an external precharge device.
1800 F2400 F 3000 F4500 F 6000 F8400 F8400 F
Short-circuit current rating 200,000 A (rms) symmetrical
