Rockwell Automation Publication 750-TG101A-EN-P - June 2022 127
Chapter 6
Frame 7 Renewal Kits Installation
This chapter provides detailed instructions for how to remove and replace
PowerFlex® 755TS frame 7 product components with renewal kit components.
Frame 7 Kits Table 5 contains the renewal kits available for PowerFlex® 755TS frame 7
products. ‘XT’ in the kit catalog number identifies a kit that can contain
protective covers and/or dielectric grease on connectors. See Renewal Kits for
PowerFlex 755TS Products with Corrosive Gas Protection (XT) on page 16
for
details.
Table 5 - Frame 7 Renewal Kits
Kit Description
Catalog Number
Instructions
Standard XT
Control Pod Access Cover
(for IP00, NEMA/UL Open Type,
IP21, NEMA/UL Type 1, and
Flange, NEMA/UL Type 4X/12 Back Enclosures)
SK-RT-AD1-F67 SK-RT-AD1-F67-XT See page 130
Cover
(for IP00, NEMA/UL Open Type,
IP21, NEMA/UL Type 1, and
Flange, NEMA/UL Type 4X/12 Back Enclosures)
SK-RT-CVR1-F7 SK-RT-CVR1-F7-XT See page 131
Control Pod Human Interface Module (HIM) Cradle
(for All Enclosure Types)
SK-RT-BZL1 SK-RT-BZL1-XT See page 131
Main Control Board SK-RT-MCB1-PF755 SK-RT-MCB1-PF755-XT See page 134
Main Control Board to Power Interface Board
Ribbon Cable
— SK-RT-PIC1-F27-XT See page 139
Backplane Circuit Board
(Kit Contains 1 Circuit Board)
SK-RT-BKPLN SK-RT-BKPLN-XT See page 141
Heatsink Fan Assembly
(for IP00, NEMA/UL Open Type and
IP21, NEMA/UL Type 1 Enclosures)
SK-RT-HSFAN1-F7 SK-RT-HSFAN1-F7-XT See page 142
Heatsink Fan Assembly
(for Flange, NEMA/UL Type 4X/12 Back and
IP54, NEMA/UL Type 12 Enclosures)
— SK-RT-HSFAN2-F7-XT See page 142
Stirring Fan Assembly
(for All Enclosure Types)
SK-RT-STIRFAN1-F7 SK-RT-STIRFAN1-F7-XT See page 144
Flange Gasket
(for Flange, NEMA/UL Type 4X/12 Back
Enclosures)
SK-RT-FG1-F7 — See page 146
Power Interface Circuit Board,
302 A 400V / 302 A 480V
SK-RT-PIB1-C302D302 SK-RT-PIB1-C302D302-XT
See page 151
Power Interface Circuit Board,
367 A 400V / 361 A 480V
SK-RT-PIB1-C367D361 SK-RT-PIB1-C367D361-XT
Power Interface Circuit Board,
456 A 400V / 415 A 480V
SK-RT-PIB1-C456D415 SK-RT-PIB1-C456D415-XT
Power Interface Circuit Board,
477 A 400V / 477 A 480V
SK-RT-PIB1-C477D477 SK-RT-PIB1-C477D477-XT
AC Precharge Circuit Board, 400/480V SK-RT-ACPC-CDF7 SK-RT-ACPC-CDF7-XT See page 161
DC Precharge Circuit Board SK-RT-DCPC-F67 SK-RT-DCPC-F67-XT See page 170
