Rockwell Automation Allen-Bradley PowerFlex 755TS Series User Manual

38 Rockwell Automation Publication 750-TG101A-EN-P - June 2022
Chapter 4 Frames 1…5 Renewal Kits Installation
Install the IP54, NEMA/UL Type 12 Cover, Frames 2…5
Follow these steps to install the cover.
1. Place the cover on the flange and finger-tighten all hardware.
2. Apply the torque value in the sequence shown.
3. Apply final torque in the sequence shown.
2
M4 x 16 mm
T20 or F - 6.4 mm (0.25 in.)
0.12 N•m (1.0 lb•in)
M4
7 mm
0.12 N•m (1.0 lb•in)
3
M4 x 16 mm
T20 or F - 6.4 mm (0.25 in.)
0.23 N•m (2.0 lb•in)
M4
7 mm
0.23 N•m (2.0 lb•in)
1
1
5
7
3
10
14 15
11
8
6
2
4
12
9
13
5
10
7
1
3
8
11
6
2
4
12 9 13
14 15
5
9
7
3
1
8
10
6
2
11 13 12
4
14 15
5
9
7
3
1
15 17 18
13
11
16
19 21 22 20
8
12
6
2
4
14
10
Frame 2 Frame 3
Frame 4
Frame 5
