Rockwell Automation Allen-Bradley PowerFlex 755TS Series

Rockwell Automation Publication 750-TG101A-EN-P - June 2022 15
Chapter 1 Before You Begin Tests, Maintenance, or Repairs
Figure 3 - Frames 6 and 7 Power Terminal Block and PE Ground Locations
Frame 7
2
1
Frame 6
3
2
4
1
3
4
Item Name
1 +DC and –DC test points
2 +DC, –DC, BR1, BR2
3 R/L1, S/L2, T/L3, U/T1, V/T2, W/T3
4PE Ground
