Rockwell Automation Publication 750-TG101A-EN-P - June 2022 23
Chapter 1 Before You Begin Tests, Maintenance, or Repairs
Figure 8 - Four-point Mounting
Figure 9 - Six-point Mounting
1
2
3
4
3 4
Initial Sequence
1
2
1
234
Final Sequence
6 42
3 51
3 4
Initial Sequence
1 2 65
Final Sequence
3 41 2 65
Do not exceed 0.7 Nm (6 lbin) on initial torque of all six screws.
