34 Rockwell Automation Publication 750-TG101A-EN-P - June 2022
Chapter 4 Frames 1…5 Renewal Kits Installation
Heatsink Fan
(
for Flange, NEMA/UL Type 4X/12 back and
IP54, NEMA/UL Type 12 Enclosures)
—
SK-RT-HSFAN2-F2-XT 2
See page 57
SK-RT-HSFAN2-F3-XT 3
SK-RT-HSFAN2-F45-XT
4
See page 58
5
Internal Stirring Fan
(for All Enclosure Types)
SK-RT-STIRFAN1-F45 SK-RT-STIRFAN1-F45-XT
4
See page 59
5
Control Pod Human Interface Module (HIM)
Cradle
(for All Enclosure Types)
SK-RT-BZL1 SK-RT-BZL1-XT
2
See page 61
3
4
5
Main Control Circuit Board SK-RT-MCB1-PF755 SK-RT-MCB1-PF755-XT
1 See page 64
2
See page 69
3
4
5
Main Control Board to Power Interface
Board Ribbon Cable
— SK-RT-PIC1-F1-XT 1 See page 74
— SK-RT-PIC1-F27-XT
2
See page 75
3
4
5
Backplane Circuit Board
(Kit Contains 1 Circuit Board)
SK-RT-BKPLN SK-RT-BKPLN-XT
1 See page 76
2
See page 77
3
4
5
EMC C3 Ground Plate (400/480V)
SK-RT-EMC3-F1
—
1
(1)
SK-RT-EMC3-F2 2
SK-RT-EMC3-F3 3
SK-RT-EMC3-F4 4
SK-RT-EMC3-F5 5
(1) The EMC C3 ground plate and hardware is shipped with the drive from the factory. These renewal kits can be purchased to replace
missing or damaged parts for the EMC C3 assembly. For installation instructions, see the PowerFlex 755TS Products with
TotalFORCE® Control Installation Instructions, publication 750-IN119
.
Table 3 - Frames 1…5 Renewal Kits (Continued)
