Chapter 4 Frames 1…5 Renewal Kits Installation
4. Remove the two M4 x 8 mm Torx screws that secure the backplane circuit
board to the pod chassis and remove the board.
4
M4 x 8 mm
T20 or F - 5 mm (0.19 in.)
2.6 N•m (23.0 lb•in)
=
Frame 2 Shown
