Rockwell Automation Publication 2198-RM006A-EN-P - December 2020 71
Appendix D Interconnect Diagrams
Figure 23 shows the power wiring diagram with 24V DC control string for
2098-DSD-075-SE and 2098-DSD-150-SE Ultra3000 Sercos drives.
For Sercos drives, input line contactor is part of the PLC program and output
control.
Figure 23 - Typical Power Wiring on Ultra3000 (230V) System
TB1
U
V
W
DC+
DC-
L1
L2
L3
L1 AUX
L2/N AUX
L2
L1
CN1
43
44
L3
TB2
1
2
3
Chassis
N.O. Relay Output+
N.O. Relay Output-
Neutral
External Passive
Shunt Connections
2098-DSD-075-SE, and
2098-DSD-150-SE
Ultra3000 Digital Servo Drives
Three-phase AC Line
50/60 Hz
Fused Disconnect
or Circuit Breaker*
Isolation
Transformer*
Three-phase Input
100…240V AC rms
Terminal
Blocks*
To additional
Ultra3000 Drive
* INDICATES USER-SUPPLIED COMPONENT
Three-phase
AC Line Filter
Input Fusing*
Input Fusing*
Bonded Cabinet
Ground Bus*
Three-phase
Motor Power
Connections
AC Input Power
Connections
Motor Power
Connections
Cable Shield
Clamp
