6-2 Optional HIM Operation
Option Action Operation
Pump Control
Pump Control The green start button, when pressed, will
commence motor acceleration to full speed.
The red stop button, when pressed, will
provide a coast stop, and/or reset a fault.
The jog button, when pressed, will initiate a
pump stop maneuver.
Braking Control
Smart Motor Braking The green start button, when pressed, will
commence motor acceleration to full speed.
The red stop button, when pressed, will
provide a coast stop, and/or reset a fault.
The jog button, when pressed, will initiate a
brake stop.
Accu-Stop The green start button, when pressed, will
commence motor acceleration to full speed.
The red stop button, when pressed, will
provide a coast stop, and/or reset a fault.
With a “stopped” status, the jog button,
when pressed, will initiate slow speed motor
operation. From an “at speed” condition, the
jog button, when pressed, will initiate
braking to slow speed operation. The
controller will maintain slow speed operation
as long as the jog button is pressed.
Slow Speed with
Braking
The green start button, when pressed, will
commence motor acceleration to full speed.
The red stop button, when pressed, will
provide a coast stop, and/or reset a fault.
The jog button will initiate a brake stop.
* Slow Speed cannot be operated via the
HIM.
I
O
Jog
I
O
Jog
I
O
Jog
I
O
Jog
ATTENTION
!
The Bulletin 20-HIM LCD Human interface
module’s stop push button is not intended to be used
as an emergency stop. Refer to applicable standards
for emergency stop requirements.
