Specifications A-5
Environmental
➀ The product’s allowable operational ambient temperature must be derated by -3 °C (-27°F) per
1000 m (3280 ft.). Maximum operating altitude is 7000 m (23,000 ft.). Current rating of the SMC-Flex
does not change for altitudes that require a lower maximum ambient temperature.
Mechanical
Operating Temperature Range
-5…+50°C (+23…+122°F) (open)
-5…+40°C (+23…+104°F) (enclosed)
Storage and Transportation Temperature
Range
–20…+75°C
Altitude
2000 m (6560 ft) ➀
Humidity
5…95% (non-condensing)
Pollution Degree
2
Resistance to
Vibration
Operational All 1.0 G Peak, 0.15 mm (0.006 in.) displacement
Non-Operat
ional
5…480 A 2.5 G, 0.38 mm (0.015 in.) displacement
625…1250 A 1.0 G Peak, 0.15 mm (0.006 in.) displacement
Resistance to
Shock
Operational
5…85 A 15 G
108…480 A 5.5 G
625…1250 A 4 G
Non-Operat
ional
5…85 A 30 G
108…480 A 25 G
625…1250 A 12 G
Construction
Power
Poles
5…85 A
Heatsink thyristor modular design
108…1250 A
Heatsink hockey puck thyristor modular design
Control Modules
Thermoset and Thermoplastic Moldings
Metal Parts
Plated Brass, Copper, or Painted Steel
Terminals
Power
Terminals
5…85 A
Cable size —
Line Upper — 2.5…95 mm
2
(14…3/0 AWG)
Line Lower — 0.8…2.5 mm
2
(18…14 AWG)
Load Upper — 2.5…50 mm
2
(14…1 AWG)
Load Lower — 0.8…2.5 mm
2
(18…14 AWG)
Tightening torque — 14.7 N•m (130 lb.-in.)
Wire strip length — 18…20 mm (0.22…0.34 in.)
108…135 A
One M10 x 1.5 diameter hole per power pole
201…251 A
Two M10 x 1.5 diameter holes per power pole
317…480 A
Two M12 x 1.75 diameter holes per power pole
625…1250 A
Two 13.5 mm (0.53 in.) diameter holes per power
pole
Power Terminal Markings
NEMA, CENELEC EN50 012
Control Terminals
M 3 screw clamp:
clamping yoke connection
