Rockwell Automation SMC-Flex User Manual

Appendix C
Renewal Parts
➀
One piece provided per part number.
➁ Three-phase power pole structure provided per part no.
➂ One-phase power pole provided per part no.
➃ See Appendix D for special installation instructions.
Description SMC Rating
Part No.
➀
For units rated 200…600V AC
For units rated 690V
AC
100…240V AC 24V AC/DC 100…240V AC
Control Modules Standard All 41391-454-01-S1FX 41391-454-02-S2FX 41391-454-05-S1FZ
Pump All 41391-454-01-B1FX 41391-454-02-B2FX 41391-454-05-B1FZ
Braking 5…85 A 41391-454-01-D1AX 41391-454-02-D2AX 41391-454-05-D1AZ
108…251 A 41391-454-01-D1BX 41391-454-02-D2BX 41391-454-05-D1BZ
317…480 A 41391-454-01-D1CX 41391-454-02-D2CX 41391-454-05-D1CZ
625…780 A 41391-454-01-D1DX N/A 41391-454-05-D1DZ
970…1250 A 41391-454-01-D1EX N/A 41391-454-05-D1EZ
Description
SMC Rating Series
Part No.
➀
Line Voltage
200…480V 200…600V 230…690V
Power Poles 5 A B 150-FPP5B ➁ 150-FPP5C ➁ N/A
25 A B 150-FPP25B ➁ 150-FPP25C ➁ N/A
43 A B 150-FPP43B ➁ 150-FPP43C ➁ N/A
60 A B 150-FPP60B ➁ 150-FPP60C ➁ N/A
85 A B 150-FPP85B ➁ 150-FPP85C ➁ N/A
108 A B 150-FPP108B ➁ 150-FPP108C ➁ 150-FPP108Z ➁
135 A B 150-FPP135B ➁ 150-FPP135C ➁ 150-FPP135Z ➁
201 A B 150-FPP201B ➂ 150-FPP201C ➂ 150-FPP201Z ➂
251 A B 150-FPP251B ➂ 150-FPP251C ➂ 150-FPP251Z ➂
317 A B 150-FPP317B ➂ 150-FPP317C ➂ 150-FPP317Z ➂
361 A B 150-FPP361B ➂ 150-FPP361C ➂ 150-FPP361Z ➂
480 A B 150-FPP480B ➂ 150-FPP480C ➂ 150-FPP480Z ➂
625 A B 150-FPP625B ➂ 150-FPP625C ➂ 150-FPP625Z ➂
780 A B 150-FPP780B ➂ 150-FPP780C ➂ 150-FPP780Z ➂
970 A B 150-FPP970B ➂ 150-FPP970C ➂ 150-FPP970Z ➂
1250 A B 150-FPP1250B ➂ 150-FPP1250C ➂ 150-FPP1250Z ➂
Heatsink Fans 5…85 A B 41391-801-03
108…135 A B 41391-801-03
201…251 A B 41391-801-01
317…480 A B 41391-801-02
110/120V AC
Control Power
625…1250 A B 41391-801-04
230/240V AC
Control Power
625…1250 A B 41391-801-05
Base Plate 201…251 A B 41391-803-01
317…480 A B 41391-803-02
By-Pass
Contactor
110/120V AC
Control Power
625…780 A B 100-D180ED11 ➃
970…1250 A B 100-D420ED11 ➃
230/240V AC
Control Power
625…780 A B 100-D180EA11 ➃
970…1250 A B 100-D420EA11 ➃
