2-4 Installation
Enclosures The open-style design of the SMC-Flex controller requires that it be
installed in an enclosure. The internal temperature of the enclosure
must be kept within the range of 0…50°C.
For Type 12 (IP54) enclosures, the following guidelines are
recommended to limit the maximum controller ambient temperature.
There should be a clearance of at least 15 cm (6 in.) above and below
the controller. This area allows air to flow through the heatsink.
Table 2.B Minimum Enclosure Size ➊
➊ Larger enclosure may be required based on options selected. Consult your local Rockwell
Automation Sales office or Allen-Bradley distributor.
➋ Use this row for 460V -58 and 575V -59.
➌ Use this row for 460V -59 and 575V -60 and -61.
Controller
Rating (A)
IP65 (Type 4/12)
B Height A Width C Depth
Non-Combination Controller [mm (in.)]
5 610 (24) 406 (16) 254 (10)
25 610 (24) 406 (16) 254 (10)
43 610 (24) 406 (16) 254 (10)
60 610 (24) 406 (16) 254 (10)
85 610 (24) 406 (16) 254 (10)
108 762 (30) 610 (24) 305 (12)
135 762 (30) 610 (24) 305 (12)
201 965 (38) 762 (30) 356 (14)
251 965 (38) 762 (30) 356 (14)
317 1295 (51) 914 (36) 356 (14)
361 1295 (51) 914 (36) 356 (14)
480 1295 (51) 914 (36) 356 (14)
625 2286 (90) 889 (35) 508 (20)
780 2286 (90) 889 (35) 508 (20)
Combination Controllers with Fusible Disconnect
5 610 (24) 406 (16) 254 (10)
25 610 (24) 406 (16) 254 (10)
43 610 (24) 406 (16) 254 (10)
60 610 (24) 406 (16) 254 (10)
85 610 (24) 406 (16) 254 (10)
108 965 (38) 762 (30) 356 (14)
135 965 (38) 762 (30) 356 (14)
201 965 (38) 762 (30) 356 (14)
251 965 (38) 762 (30) 356 (14)
317 1524 (60) 965 (38) 356 (14)
361 1524 (60) 965 (38) 356 (14)
480 ➊ 1524 (60) 965 (38) 356 (14)
480 ➋ 2286 (90) 889 (35) 508 (20)
625 2286 (90) 1397 (55) 508 (20)
780 2286 (90) 1397 (55) 508 (20)
Combination Controllers with Circuit Breaker
5 610 (24) 406 (16) 254 (10)
25 610 (24) 406 (16) 254 (10)
43 610 (24) 406 (16) 254 (10)
60 610 (24) 406 (16) 254 (10)
85 610 (24) 406 (16) 254 (10)
108 965 (38) 762 (30) 356 (14)
135 965 (38) 762 (30) 356 (14)
201 965 (38) 762 (30) 356 (14)
251 965 (38) 762 (30) 356 (14)
317 1295 (51) 914 (36) 356 (14)
361 1295 (51) 914 (36) 356 (14)
480 1295 (51) 914 (36) 356 (14)
625 2286 (90) 1397 (55) 508 (20)
780 2286 (90) 1397 (55) 508 (20)
