Rockwell Automation SMC-Flex User Manual

A-6 Specifications
Other
Approximate Dimensions and
Shipping Weights
Open Type Controllers
Dimensions are in millimeters (inches). Dimensions are not intended
for manufacturing purposes.
EMC Emission Levels
Conducted Radio Frequency
Emissions
Class A
Radiated Emissions
Class A
EMC Immunity
Levels
Electrostatic Discharge
8 kV Air Discharge
Radio Frequency
Electromagnetic Field
Per EN/IEC 60947-4-2
Fast Transient
Per EN/IEC 60947-4-2
Surge Transient
Per EN/IEC 60947-4-2
Overload
Characteristics
Current Range
Line Delta
5
1…5 1.7…9
25
5…25 8.6…43
43
8.6…43 14.8…75
60
12…60 20.8…104
85
17…85 29.4…147
108
27…108 47…187
135
34…135 59…234
201
67…201 116…348
251
84…251 145…435
317
106…317 183…549
361
120…361 208…625
480
160…480 277…831
625
208…625 283…850
780
260…780 300…900
970
323…970 400…1200
1250
416…1250 533…1600
Trip Classes
Trip Current Rating
Number of Poles
10, 15, 20, and 30
117% of Motor FLC
3
Certifications Open Type Controllers
CE Marked Per Low Voltage Directive
73/23/EEC, 93/68/EEC
UL Listed (File No. E96956)
Controller
Rating (A)
Height Width Depth
Approximate
Shipping
Weight
5…85
321
(12.6)
150
(5.9)
203
(8.0)
5.7 kg
(12.6 lb.)
108…135
443.7
(17.47)
196.4
(7.74)
205.2
(8.08)
15.0 kg
(33 lb.)
201…251
560
(22.05)
225
(8.86)
253.8
(9.99)
30.4 kg
(67 lb.)
317…480
600
(23.62)
290
(11.42)
276.5
(10.89)
45.8 kg
(101 lb.)
625…780
1041.1
(41.0)
596.9
(23.5)
346.2
(13.63)
179 kg
(395 lb.)
970…1250
1041.1
(41.0)
596.9
(23.5)
346.2
(13.63)
224 kg
(495 lb.)
